Spring cone crusher lubrication system operating procedures
1, spring cone crusher lubrication system is the system working pressure and oil temperature, the operating temperature of the the two pressure controller action pressure and temperature controller adjusted to set the value of the corresponding position (factory setting is the initial settings can be set separately according to the host requirements), open the corresponding oil line valve lubrication oil station.
2, spring cone crusher lubrication system oil temperature according to the system requirements necessary first open oil electric heater, circulating oil is heated to the working temperature.
Spring cone crusher lubrication system in the host before work, first open the oil pump, the system reaches a certain pressure, and then start the host. Host after you stop working, and then stop the pump.
Spring cone crusher thin oil lubrication system lubrication oil station, oil pressure, oil temperature, oil level is not normal circumstances, there is a corresponding signal light and horn alarm, first uninstall the horn, and then the failure to take measures to deal with the fault lights display.
5, thin oil standing working oil pressure gauge on the instrument panel should be observed at any time, should be shut down when the differential pressure exceeds 0.05Mpa work filter cleaning or replacement.
